mineral wool sandwich panel with steel sheet

FOB Reference Price:Get Latest Price
$15.00 - $30.00 / Meters | 100 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hebei, China (Mainland)
Brand Name:
mineral wool sandwich panel with steel sheet
Model Number:
sandwich panel-11
Material:
Sandwich Panel
Use:
Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, Warehouse, Workshop,Plant, mineral wool sandwich panel with steel sheet
usage::
house,villa,home
material::
eps, pu, rock wool
cost::
lower cost than traditional building material
installation::
quick
shippment::
flat pack
size:
:according to customer's design
life span::
over 30 years
safety::
anti-wind,anti-earthquake,waterproof,fireproof
mobility::
disassemble or completed lifting
environment-friendly::
recycling material
Supply Ability
Supply Ability:
60000 Meter/Meters per Month
Packaging & Delivery
Packaging Details
bare bundle in container
Port
Tianjin Xingang Port, China
Lead Time :
about 15-30 days after deposit

Specifications

mineral wool sandwich panel with steel sheet
1.Heating insulation, strong corrosion resistance.
2.High mechanical strength

  mineral wool sandwich panel with steel sheet



Description:

WHAT ARE INSULATED SANDWICH PANELS?

Insulated Sandwich Panels (ISP) have been used for commercial construction in the past 50 years. Insulated Sandwich Panels (ISP) are made when three separate elements are “sandwiched together” to form one structure. The combined properties of the high tensile and compressive strength of the outer steel skins and the high shear strength of the inner core leads to a building material which has a much longer spanning capacity and is lighter in weight than traditional building materials.



The sandwich panels interlock simply, slipping easily into place, quickly locking panels tightly together to create a high performing and consistent insulation barrier protecting the home from variations in outside temperatures and humidity and maintaining a comfortable internal living environment.



The sandwich panel is up to 50% faster to install than conventional roofing including trusses and insulation. Large spans are achievable, reducing the need for support structures and enabling spacious living areas.



It offers an attractive smooth ceiling without the need for plastering or painting and superior thermal performance when compared to a traditional roofing system and maintains its insulating integrity for the life of the home.

Specifications:





ITEM

DESCRIPTION

Wall / Roof Panel surface

Color galvanized steel sheet

Thickness:

50 / 75 / 100mm

Length

5.95M (consider the container loading)

Width

950 / 960 / 1000 MM

Thickness of the upper plate

0.2 to 0.6mm galvanized

Thickness of the bottom plate

0.2 to 0.6mm  galvanized

Raw materials:

polystyrene  ( EPS )

Surface

Flat or Corrugated

Density

EPS: 8 to 15kgs/m3

Rock Wool:80 to 100kgs/m3

PU: 42kgs/m3

Color

Standard is white, blue and red …



Applications:



Wall or roof panel, clean board, insulated panel, insulated sound panel…

Industrial steel structure building, Remote site constructions camping, Warehouse, Work shop…

Family house, sandwich panel prefab house, sandwich panel container house, sandwich panel portable house, sandwich panel movable house…



Competitive Advantage:

  1. The sandwich panel has excellent insulating performance: heat insulation, sound insulation, waterproof performance, etc.
  2. Light dead weight, high mechanical strength, excellent shearing resistant performance, strong corrosion Resistance, high durability, and weather fastness, etc.
  3. It is easy to install and can be used many times over.
  4. Nowadays, the sandwich panel is widely used for cleaning workshops, industrial factory buildings, office buildings, stadiums, villas, and public buildings, etc.







Last Update Time:2014-03-14
